FUNCTIONS

  1.  Recycle remaining refrigerant in the automobile air conditioner.

  2.  After treatment, the recycled refrigerant accords with SAE standard.

  3.  Separate and drain A/C system oil.

  4.  Electro-magnetic valve controls the injection of A/C system oil.

  5.  Automatically remove the incondensable gases in refrigerant.

  6.  Electronic balance measures the recycled and recharged refrigerant during the whole process.


  CHARACTERISTICS

  1.   Micro-computer controls the whole process.

  2.   Liquid crystal bright background display.

  3.   Language chart includes Chinese, English, Korean, Russian and Arabic.

  4.   Electro-magnetic valve design prevents damage from liquid flow.

  5.   Fast and convenient self-sealing connections.

  6.   Automatic reminding of problem checking and alarming.

  7.   Automatic reminding of present operation states.

  8.   Automatic reminding of daily maintenance.


  SPECIFICATIONS

  Recovery Speed: 3 g/s

  Recycling Speed: 8.0 g/s

  Vacuum Speed: 1.0 g/s

  Recharging Speed: 18g/s

  Scale Accuracy: ±10g/s

  Work Tank Capacity: 10kg

   Dry Filter Capability: 60kg R134a
