FUNCTIONS

  1.   Automatically recycle remaining refrigerant.

  2.   After treatment, the recycled remaining refrigerant accords with SAE standard.

  3.   Automatically separate and drain A/C system oil.

  4.   Electro-magnetic valve controls the adding of A/C system oil.

  5.   Automatically treats the incondensable gases in refrigerant.

  6.   Electronic balance measures the recycled and recharged refrigerant during the whole process.

  7.   After one set up, the whole process of vacuuming and recharging of the refrigerant will be completed automatically.

  8.   The pressure and temperature comparing table can tell if automobile air conditioner operates properly.


  CHARACTERISTICS

  1.   Language guides the operation, liquid crystal large screen bright background display.

  2.   The whole process is controlled by micro-computer, electro-magnetic valve design prevents damage from liquid flow.

  3.   Fast and convenient self-sealing connections.

  4.   Automatic reminding of problem checking and alarming.

  5.   Automatic reminding of present operation states.

  6.   Automatic reminding of daily maintenance.

  SPECIFICATIONS

  Recovery Speed: 11.0 g/s

  Recycling Speed: 13.0 g/s

  Vacuum Speed: 3.2 g/s

  Recharging Speed: 38g/s

  Scale Accuracy: ±10g/s

  Work Tank Capacity: 12kg

   Dry Filter Capability: 168kg R134a
